*Updated* mr.415 - Ableton Push Traktor 4Deck w/full LED (mr415 edit)
Description and Instructions
*UPDATED FROM VIDEO, current version documented below*
*No EQ functions* --> Best if paired with a four channel-capable mixer controller like a Behringer MM1, or if used with an external mixer/4channel soundcard setup.
Setup --> Enable 4 Deck, Advanced View on all decks.
Includes:
Shift Button/Modifier Controls (Hold Mode)
* Shift Button 1/Modifier 1 = Ableton Push Play button
* Shift Button 2/Modifier 2 = Ableton Push Record button
Play/Pause/Sync (Green = Play/Pause, Yellow = Sync On/Off)
* Beatphase on play button
* Shift Button 1 hold --> Master Tempo deck selection and LED feedback
Looping/loop length (Purple = Loop On/Off, Green = Loop Length)
* Shift Button 1 hold + Loop On = Loop IN
* Shift Button 1 hold + Unlit button next to Loop On = Loop Out
Beatjump (Dark Blue = Backward/Beatjump Value decrease, Light Blue = Forward/Beatjump Value Increase)
* Beatjump Forward and Back
* Shift Button 1 hold + Beatjump forward = Beatjump Value increase
* Shift Button 1 hold + Beatjump Backward = Beatjump Value Decrease
Eight Cue Point buttons, with Grid Point and Delete (Colors = Different Per Deck, Lit/Unlit depending on cue point presence)
* Cue Point Button = Set Hot Cue Point
* Shift Button 1 Hold + Hot Cue Button = Delete Cue Point
* Shift Button 2 Hold + Hot Cue Button 1 = Set Gridpoint
Filter (Knobs 1, 3, 5, and 7 + Pitch Bend Strip)
* Shift Button 1 hold + Turn = Volume Adjust
* Shift Button 2 hold + Touch = Filter Reset
* Pitch Bend Strip = 4 Deck Filter Control
* Pitch Bend Strip controls all four deck filters at once, resets when let go
Jogwheel/Tempo Adjust (Knobs 2, 4, 6, and 8 + Second Row of small buttons, yellow)
* Turn while playing = Jogwheel Turn
* Turn while paused = Jogwheel Scratch
* Shift Button 1 hold + Turn = Tempo Adjust
* Turn sensitivity can be fine tuned in controller manager
* Tempo Adjust Buttons (Bright Yellow = Tempo Increase, Dim Yellow = Tempo Decrease)
* Shift Button 1 Hold + Either Tempo Adjust Button = Reset Tempo (Per deck)
Full browsing and loading with browser only toggle
* Tap Tempo Button = Browser Only
* Metronome button = Folder Expand/Collapse
* Small Click Encoder Turn = Song List Scroll
* Shift Button 1 hold + Click Encoder Turn = Folder List Scroll
* Red Buttons Top Row = Load selected song to deck
Full monitor cueing with cue mix and volume
* Unlit Buttons Top Row = Headphone Cue Deck Select
* Green when selected
* Small Encoder Turn = Headphone Mix
* Shift Button 1 hold + Small Encoder Turn = Headphone Volume
Master Volume Adjust
* Ableton Push Master Volume Encoder
Flux Toggle
*Shift Button 1 hold + Headphone Cue Deck Select = Flux mode toggle (LED Feedback included)
Please leave any comments, criticisms, ideas, or edits below!
